Features:
Electrohyrdraulic
operation
Clockwise
and counter clockwise rotation of the clamp range from 14"-56"
Movable
controlling unit
Hydraulic
motor with pressure adjustment device
Movable
tool carrier arm and the bottom bracket
Adjustable
clamping force
Mounting
head can be rotating at high speed automatically
Teknik Özellikler:
Pump
motor: 2.2kw
Rotating
motor: 2.2kw
Power
supply: 220V/400V
Clamping
capacity: 14"-56"
Maximum
tire diameter: 2300mm
Maximum
tire width: 1065mm
Maximum
tire weight: 1600 kg
Package
size: 2100x1700x1000 mm
Weight:
840/890 kg
|
|
 |
